Endless Pools - E500
Go-to destination for family fun and fitness
Our most compact swim spa to feature our signature adjustable current. Swim, workout, and play, then unwind with powerhouse hydromassage jets!
Seating Capacity
3
Water Capacity
1,735 Gallons
Dimensions
15’ L x 7'5” W x 4'2" H 457 cm L x 226 cm W x 127 cm H
Depth 48" (122 cm)
Depth 48" (122 cm)
Weight
Dry:3,030 LbsFilled:19,235 Lbs
Total Jets
27
Additional Specifications
Hydromassage Jets - 27
1 Large Jet, 2 Rotary Jets, 2 Directional Jets, 22 Mini Jets
Hydromassage Jet Pump
2.5 HP Continuous Duty; 5.2 HP Breakdown Torque - 1 Speed Pump
Electrical Requirements
230v/30amp; 230v/60amp (optional), includes GFCI sub-panel
Swim Power Unit /strong>
5 HP Hydraulic Power Un
Heater
4000w/230v
Current
Hydrodrive™ Technology
1:08/100 yd (1:11/100 m) max pace with 31 pace settings
1:08/100 yd (1:11/100 m) max pace with 31 pace settings
Control System
Touchscreen Control Panel; 230v/60amp, 60 Hz, includes G.F.C.I. protected sub-panel
Water Care System
UVC + CD Ozone
Water Features
2 Illuminated Waterfalls
Effective Filtration Area
200 Square Feel
Lighting System
18 Multi-Color LED Points of Light & Exterior LED Illumination Bar
Substructure
14-Gauge Galvanized Steel Frame with Thermoformed ABS Base Pan
Energy Efficiency
Certified to the APSP 14 National Standard and the California Energy
Commission (CEC) in accordance with California Law
Commission (CEC) in accordance with California Law
Music Option
8 Speakers + Subwoofer, Bluetooth® Enabled
